SGM7SZ86.pdf? Ultra-High Speed: tPD = 4.2ns (TYP) into 50pF
at VCC = 3.3V
? High Output Drive: ±24mA at VCC = 3V
? Broad VCC Operating Range: 1.65V to 5.5V
? Matches Performance of LCX Operated at VCC = 3.3V
? Power Down High-Impedance Inputs/Output
? Over-Voltage Tolerance Inputs Facilitate 5V to 3V
Translation
? Available in Green SOT-23-5 and SC70-5 Packages
? High Speed: tPD = 4.8 ns (Typ) at VCC = 5 V
? Low Power Dissipation: ICC = 1μA (Max) at TA = 25°C
? TTL?Compatible Inputs: VIL = 0.8 V; VIH = 2 V
? CMOS?Compatible Outputs:
VOH > 0.8 VCC; VOL < 0.1 VCC @Load
? Power Down Protection Provided
on Inputs and Outputs
? Balanced Propagation Delays
? Pin and Function Compatible with
Other Standard Logic Families
? Chip Complexity:
FETs = 83; Equivalent Gates = 16
? Pb?Free Packages are Available
