SGM41100.pdf? Ultra Compact Protection Solution
? 44mΩ Pass Resistance
? 1μA Operation Current
? Factory Programmable OVP Threshold Options
4.20V to 4.55V with 0.05V per Step
? Over-Charge/Discharge Current Protection
4 Thresholds Combination Options
? Battery Under-Voltage Protection
2.4V/2.5V/2.8V/3.0V Options
? 100nA Deep Discharging Shutdown
? Exhausted Battery Charging from 0.2V
? Input Surge Clamping
? Input Over-Voltage Safe
? Load Short-Circuit Safe
? Reverse Polarity Battery Safe
? Input Reversed-Attaching Safe
? Battery Pack Paralleling Safe
? Locked-Off for Delivery/Assembly
? Available in Green UTDFN-1.5×2-6L Package
? Protection of Charger Reverse Connection
? Protection of Battery Cell Reverse Connection
? Integrate Advanced Power MOSFET with Equivalent of 45m? RSS(ON)
? Ultra-small DFN2X2-6 Package
? Only One External Capacitor Required
? Over-temperature Protection
? Overcharge Current Protection
? Two-step Overcurrent Detection:
Overdischarge Current
Load Short Circuiting
? Charger Detection Function
? 0V Battery Charging Function
? Delay Times are generated inside
? High-accuracy Voltage Detection
? Low Current Consumption
Operation Mode: 2.8μ A typ.
Power-down Mode: 1.5μ A typ.
? RoHS Compliant and Lead (Pb) Free
