SGM2036.pdf? Low Dropout Voltage
? Thermal Overload Protection
? Built-In Fold Back Protection Circuit
? 20μA Low Supply Current
? 10nA Logic-Controlled Shutdown
? 1.6V to 5.5V Input Voltage Range
? Fixed Outputs of 0.8V, 0.9V, 1.0V, 1.05V,
1.1V, 1.2V, 1.3V, 1.35V, 1.5V, 1.8V, 1.85V,
2.1V, 2.2V, 2.3V, 2.5V, 2.6V, 2.7V, 2.8V,
2.85V, 2.9V, 3.0V, 3.1V, 3.3V, 3.6V,
4.2V, 4.4V and 5.0V
? Adjustable Output from 0.8V to 5.0V
? Short Auto-Discharge Function
? 300mA Output Current
? High Output Voltage Accuracy
? Short Start-Up Time
? -40℃ to +85℃ Operating Temperature Range
? Available in Green UTDFN-1×1-4L,
SOT-23-5 and SC70-5 Packages
? Input Voltage Range: 1.8 V to 5.5 V
? Output Voltage Range: 1.3 V to 3.7 V
? Excellent Line Transient Response: ±2 mV(typical)
? Excellent PSRR: –60 dB at 1 kHz typical
? Low Quiescent Current of 29 μA typical
? Small SC70-5 and SOT-23-5 Packages
? Fast Turnon Time of 30 μs typ.
? Typical < 1 nA Quiescent Current in Shutdown
? Ensured 150-mA Output Current
? Logic Controlled Enable 0.4 V/0.9 V
? Good Load Transient Response of 50 mVpp (typical)
? Thermal Overload and Short-Circuit Protection
? -40°C to 125°C Junction Temperature Range
